Specification
Sink Faucet Deckmount
8" deck LESS hose and spray - CER-TECK® ceramic
structures
Model No: 27C2942
SPECIFICATION:
•
Below deckmount sink faucet
•
203 mm (8") centers, two handle
•
Polished chrome plated finish
•
Cast brass bodies
•
Metal hold-down package
•
CER-TECK® ceramic structures
•
Spout#: 9 - Gooseneck spout-6.0" radius- 10.4" height (unmounted)-
Standard rigid/swivel field installation unless LS Limited swing option
selected- Vandal resistant .090" wall thickness-(R4)
•
Outlet#: 4 - Standard 1.5 GPM (5.7 L/Min) Flow Control Aerator
•
Handle#: 2 - 102 mm (4") Hooded Blade Handles-ADA compliant-Metal-
Color indexed-Vandal resistant screws
COMPLIES WITH:
•
Verified compliant with 0.25% weighted average Pb content regulations
•
CSA certified.
•
Complies to ASME A112.18.1/CSA B125.1
•
(Contact Delta Representative for State and/or Local Approvals)
•
102 mm (4") Hooded Blade Handle ADA compliant and meets Handicapped
Accessibility Standard ICC/ANSI A117.1 of less than 5 lbs operating force.
(Dimensional drawing on following page)
•
Not Available
OPERATION:
NOTES:
Verified to <0.25% Pb average wetted surface regulations
CA/VT Compliance:
This COMPLETE SERIES is ONLY available as CA/VT Compliant product
as of Nov. 1, 2009.
The Product Numbers have NOT changed.
Delta reserves the right (1) to make changes to specifications and materials, and (2) to change or discontinue models, both without notice or obligation. Dimensions are for reference.
Measurement may vary plus or minus 6mm(0.25"). Mounting locations are suggested only. Check with local codes for requirements in your area. This spec was produced February 05, 2014.
