Dimensions Guide

51579
▲
1.75 GPM
Submitted Model No.:
▲ Designate proper nish sufx
Delta reserves the right (1) to make changes in specications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for nish options and product availability.
DSP-B-51579 Rev. B
Slide Bar HandShower
STANDARD SPECIFICATIONS:
WARRANTY
COMPLIES WITH
• Maximum 1.75 gpm @ 80 psi,6.6 L/min @ 550 kPa
• Certif ied dual neoperl check valves for backf low
protection
• Hand held shower with single spray setting -- not a
positive shut-off
• Spray face rotates 360 degrees
• 60" - 82" (1524mm - 2083mm) stretchable metal hose
• Wall bar bracket for hands-free showering
• Wall bar w/adjustable slide (allows for adjustable shower
height). Not to be used as a grab bar.
Specic Features:
• Lifetime limited warranty on parts (other than electronic
parts and batteries) and inishes; or,for commercial users,
for 5 years from the date of purchase.
• 5 year limited warranty on electronic parts (other than
batteries); or for commercial users, for 1 year from the
date of purchase. No warranty is provided on batteries.
24 5/8"
(625.5 mm)
6 1/2"
(165 mm)
Single Spray Setting
51579
▲
2 13/16"
(71 mm)
2 5/16"
(58 mm)
11 7/16"
(290 mm)
• ASME A112.18.1 / CSA B125.1
• EPA WaterSense
®
19 9/16"
(498 mm)
22 3/4"
(578 mm)
= Adjustable H
2
Okinetic
™
Spray (AH
2
O)
= Soft Full Spray (SF)
= Shampoo Rinsing Spray (SR)
= Shampoo Rinsing Spray w/Massage (SRM)
=
Full Spray w/Massage (FSM)
= High-Efficiency Spray (HE)
= Crossing Full Spray (CF)
= Crossing Full Spray w/Massage (CFM)
= Fast Massage (FM)
= Soft Drench w/Full Spray (SDF)
= Soft Rain Spray (SRS)
= Soft Drench Spray (SD)
= Pause (P)
= Full Body Spray (FB)
= Adjustable Full Spray (AF)
SR
CF
CFM
HE
SDF
AF
SRM
SF
FB
SD
P
FSM
FM
= Massage Spray (M)
M
= Slow Massage (SM)
SM
= H
2
Okinetic
™
Spray (H
2
O)
= H
2
Okinetic
™
Spray w/Massage (H
2
OM)
H
2
O
H
2
OM
= Soft Drench Spray w/Massage (SDM)
SDM
AH
2
O
SRS
H2Okinetic
Spray
60" - 82"
(1524 mm-2083 mm)
Delta Faucet Company
55 E. 111th Street, Indianapolis, IN 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2017 Delta Faucet Company
FEATURES:
• H
2
Okinetic
®
Technology Handshower
