Specification

Arzo

MATERIALS: Post - Zinc Die Cast

Paper Holder - Zinc Die Cast

Wall Plate - Steel, Zinc Plated

INSTALLATION: Mount wall plate bracket(s) per installation instructions with supplied

fasteners. Slip product over wall plate(s) and tighten set screws until secure.

OPTIONAL FASTENER INFORMATION:

Wood blocking is preferable behind all wall surfaces. If wood blocking is

not available, the following fasteners are suggested:

Tile/Masonry - Plastic or Lead Anchors, Plaster/Drywall - Toggle Bolts.

SPECIFICATION: Surface mounted toilet paper holder shall be model ____________________________

(fill in model number) by Liberty Hardware Manufacturing Corporation.

TOILET PAPER HOLDER

TECHNICAL DATA

Arzo

MATERIALS: Post - Zinc Die Cast

Ring - Zinc Die Cast

Wall Plate - Steel, Zinc Plated

INSTALLATION: Mount wall plate bracket(s) per installation instructions with supplied

fasteners. Slip product over wall plate(s) and tighten set screws until secure.

OPTIONAL FASTENER INFORMATION:

Wood blocking is preferable behind all wall surfaces. If wood blocking is not

available, the following fasteners are suggested:

Tile/Masonry - Plastic or Lead Anchors, Plaster/Drywall - Toggle Bolts.

SPECIFICATION: Surface mounted towel ring shall be model__________________________

(fill in model number) by Liberty Hardware Manufacturing Corporation.

TOWEL RING

7-5/32"

[ mm]181.75

7-1/16"

[mm]180

2-1/8"

[ mm]54

3-9/16"

[ mm]89.49

2-1/8"

[mm]54

5-9/16"

[mm]141.67

5-13/16"

[ mm]147.65

3-9/16"

[ mm]89.99

3-15/16"

[ mm]99.93
