STANDARD SPECIFICATIONS

Submitted Model No.:

Specific Features:

DSP-L-597LF Rev. G

597LF-▲MPU

with Escutcheon

597LF-▲MPU

797LF▲

▲ Designate proper finish suffix

55 E. 111th Street, Indianapolis, Indiana 46280

350 South Edgeware Road, St. Thomas, Ontario

Canada N5P 4L1

Min.2 1/2" (64 mm)

Clearance to Back

Splash Recommended

Cassidy™ Series

Single Handle Deck Mount

6 13/16"

(173 mm)

6 1/8"

(57mm)

Max. Deck

Thickness

2 1/4"

(156 mm)

4 3/8"

(111 mm)

5 13/32"

(137mm)

5 27/32"

(148 mm)

2 3/32"

(53 mm)

3 13/32"

(87 mm)

6 3/8"

(162 mm)

2 3/8"

(60 mm)

3 9/16"

(91 mm)

1/2"-14 NPSM

adapters

Copper Tubing

5/16-18 UNC

3/8" O.D.

5 1/2"

(38mm)

Max. Deck

Thickness

1 1/2"

(140 mm)

3 11/16"

(94 mm)

8 5/16"

(211 mm)

11 1/8"

(283mm)

9 31/32"

(253mm)

10 1/32"

(255mm)

5 13/32"

(137mm)

1/2"-14 NPSM

adapters

Copper Tubing

5/16-18 UNC

3/8" O.D.

• One or three hole mount

• Solid brass fabricated body

• Control mechanism is replaceable cartridge with

ceramic plates

5 7/32"

(133 mm)

1 3/8"

(35 mm)

2 1/8"

(54 mm)

5 9/32"

(134 mm)

1 1/8"~1 1/2"

(29~38 mm)

Hole Size

1 1/8"~1 1/2"

(29~38 mm)

Hole Size

Min.2 1/2" (64 mm)

Clearance to Back

Splash Recommended

2 3/8"

(60 mm)

LAVATORY FAUCET

1 1/4"

(32 mm) Dia.

2 1/8"

(54 mm) Dia.

3 3/8"

(86 mm)

1 5/8"

(41 mm)

to 2 3/8"

(60 mm)

1 3/8"

(35 mm) Dia.

4 5/8"

(117 mm)

11 9/16"

(294 mm)

3 13/32"

(87 mm)

2 3/32"

(53 mm)

Metal Pop-Up (597LF only)

Single Hole Riser Models

• Models have metal drain with pop-up type

fitting with plated flange and stopper (597LF only)

• Maximum 1.20 gpm @ 60 psi, 4.54 L/min @ 414 kPa

COMPLIES WITH:

•

ASME A112.18.1/ CSA B125.1

•

ASME A112.18.2 / CSA B125.2

Indicates compliance to

ICC/ANSI A117.1

•

Verified compliant with 0.25% weighted average

Pb content regulations.

• EPA WaterSense
