Specification

1"
(25mm)
27 1/16"
(687 mm)
16 1/2"
(420 mm)
6 1/4"
15/16"-14UNS-1
3/8" NPT Supply
5" (127 mm)
Typical Range
For Existing Supply
Thread
8 1/2"
(216 mm)
16 3/4"
(425 mm)
9"
(229 mm)
12"
(305 mm)
(159 mm)
20"
(508 mm)
14 3/8"
(365 mm)
8"
(204 mm)
8"
(204 mm)
16 1/2"
(420 mm)
32 15/16"
(837 mm)
Clearance to
Back Wall
Recommended
Round Bowl
5 5/8"-6 3/8"
(142-163 mm)
Mounting Hole
5 1/2"(140 mm)
C/L of Seat Post Holes Centers
Top down view
Left view
Foot print
Brevard FlushIQ™
TOILET
C41903T
▲
C/L of Outlet
C41903T
Front view
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change ordiscontinue models, both without notice or obligation. Dimensions are for reference only.
See full-line pricebook or www.deltatoilet.com for finish options and product availability.
▲ Designate proper finish suffix (-WH for white)
DSP-S-C41903T Rev. A
