Specification

Liberty Hardware Manufacturing Corporation • 140 Business Park Drive • Winston-Salem, NC 27107 • 800.542.3789 • www.libertyhardware.com
©2011 LHMC, A Masco Company
"B"
"A"
2 9/32"
[58.0 mm]
2 17/32"
[64.6 mm]
Greenwich
ASSIST BAR ASSEMBLY
LENGTH A (Centre to Centre) B (Total length)
9" 9" (228.6 mm) 11 9/32" (286.6 mm)
12" 12" (304.8 mm) 14 9/32" (362.8 mm)
16" 16" (406.4 mm) 18 9/32" (464.4 mm)
18" 18" (457.2 mm) 20 9/32" (515.2 mm)
24" 24" (609.6 mm) 26 9/32" (667.6 mm)
MATERIALS: Assist bar is constructed using 7/8" diameter 20 gauge stainless steel tubing.
Decorative post is cast in zinc.Meets ADA and ANSI A117.1-2003 for form and
load bearing requirements
INSTALLATION: Install Assist bar with 3 - #10 x 2-1/2” flat head stainless steel screws provided for
each end wall flange.
OPTIONAL FASTENER INFORMATION:
Wall studs or Wood blocking is preferable behind all wall surfaces. If wood blocking is
not available, the following fasteners are suggested: Non-Stud Wall anchor.
SPECIFICATION: Surface mounted Assist Bar shall be model___________________________
(fill in model number) by Liberty Hardware Manufacturing Corporation.
