Technical Specifications

Submitted Model No.:
_______________________________________________
Specific Features:
__________________________________________________
T14038
T14238
T14438
T14438
7"
(178 mm)
Dia.
2 3/4"
(70 mm)
Face of plasterguard
should be flush with
finish wall line
Supply
2 3/4"
(68.6 mm)
6 3/4
"
(171 mm)
8" (203 mm)
min.
8" (203 mm)
min.
8" (203 mm)
18" (457 mm)
max.
RP
51303
▲
(Pull-Up Diverter)
3 3/8"
(86 mm)
2
7/8"
(73 mm)
RP
41589
▲
Touch
-Clean
®
S
howerhead
howerhead
howerhead
Full Spray
TUB AND SHOWER
FAUCET TRIM
■
Lahara™ Bath Collection
■
Valve Only (T14038)
■
Shower Only (T14238)
■
Tub/Shower (T14438)
STANDARD SPECIFICATIONS:
•
Monitor
®
14 Series pressure balanced bath
mixing valve with Scald-Guard
®
14 Series pressure balanced bath
®
14 Series pressure balanced bath
.
•
Maintains a balanced pressure of hot and cold
water even when a valve is turned on or off
elsewhere in the system.
•
For use with MultiChoice™ Universal rough
valve body. (R10000 Series)
•
Back-to-back installation capability.
•
Solid brass forged body.
•
Temperature only controlled with handle.
•
Field adjustable to limit handle rotation into
hot water zone.
•
120° maximum handle rotation.
•
All parts replaceable from the front of the valve.
0
1
2
3
4
5
0 10 20 30 40 50 60 70 80 9
0
Pressure (PSI)
Flow (U.S. Gallons Per Minute)
6
0 69 138 207 276 345 414 483 552 621
0
3.8
7.6
11.4
15.1
18.9
22.7
Pressure (kPa)
Flow (Liters Per Minute)
Showerhead
7
26.5
Tub Filler
30.3
34.1
8
9
®
®
U
P
C
COMPLIES WITH:
•
ASME A112.18.1 / CSA B125.1
•
ASSE 1016
Indicates ADA compliance to
ICC/ANSI A117.1
WARRANTY
•
Lifetime Faucet and Finish Limited Warranty
to the original consumer purchaser to be free
from defects in material and workmanship.
•
5 Year Limited Warranty for usage in all industrial,
commercial and business applications.
