Specification

Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
T17067▲
T17267▲
Tub AND SHOWER
FAuCET TRIM
■ Ara™ Bath Collection
■ Valve Only (T17067)
■ Shower Only (T17267)
■ Tub/Shower (T17467)
0
1
2
3
4
5
0102030405060708090
Pressure (PSI)
)etuniM reP snollaG .S.U( wolF
6
069 138 207 276 345 414 483 552 621
0
3.8
7.6
11.4
15.1
18.9
22.7
Pressure (kPa)
)et
uniM reP sretiL(
w
olF
Tub Filler
H2O Showerhead
®
COMPLIES WITH:
• ASME A112.18.1 / CSA B125.1
Indicates compliance to
ICC/ANSI A117.1 - Valve control only.
• EPA WaterSense
®
DSP-B-T17067 Rev. B
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.
T17467▲
▲ Designate Proper Finish Suffix
55 E 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2014 Masco Corporation of Indiana
2 3/4"
(70 mm)
Face of plasterguard
should be flush with
finish wall line
Supply
8" (203 mm)
min.
18" (457 mm)
max.
6 1/2"
(165 mm)
Dia.
C/L
Supply
Lines
STANDARD SPECIFICATIONS:
• Monitor
®
17 Series pressure balanced bath
mixing valve trim.
• Maintains a balanced pressure of hot and cold
water even when a valve is turned on or off
elsewhere in the system.
• Single function H
2
Okinetic
®
Technology
showerhead; 2.0 gpm @ 80 PSI.
• For use with MultiChoice
®
Universal rough
valve body. (R10000 Series)
• Back-to-back installation capability.
• Solid brass forged body.
• Lever volume control handle; temperature
adjustment dial.
• Field adjustable to limit handle rotation into
hot water zone.
• Maximum dial rotation adjustable between 90º
and 180º.
• All parts replaceable from the front of the valve.
• Red/blue temperature indicators on the
temperature adjustment dial.
WARRANTy
• Lifetime limited warranty on parts (other than
electronic parts and batteries) and finishes:
or, for commercial users, for 5 years from
date of purchase.
• 5 year limited warranty on electronic parts
(other than batteries); or, for commercial
users, for 1 year from the date of purchase.
No warranty is provided on batteries.
RP70171▲ H
2
O Showerhead
= Adjustable H
2
Okinetic
™
Spray (AH
2
O)
= Soft Full Spray (SF)
= Shampoo Rinsing Spray (SR)
= Shampoo Rinsing Spray w/Massage (SRM)
=
Full Spray w/Massage (FSM)
= High-Efficiency Spray (HE)
= Crossing Full Spray (CF)
= Crossing Full Spray w/Massage (CFM)
= Fast Massage (FM)
= Soft Drench w/Full Spray (SDF)
= Soft Rain Spray (SRS)
= Soft Drench Spray (SD)
= Pause (P)
= Full Body Spray (FB)
= Adjustable Full Spray (AF)
SR
CF
CFM
HE
SDF
AF
SRM
SF
FB
SD
P
FSM
FM
= Massage Spray (M)
M
= Slow Massage (SM)
SM
= H
2
Okinetic
™
Spray (H
2
O)
= H
2
Okinetic
™
Spray w/Massage (H
2
OM)
H
2
O
H
2
OM
= Soft Drench Spray w/Massage (SDM)
SDM
AH
2
O
SRS
H2Okinetic
Spray
RP75435▲ Pull-Up Diverter Tub Spout
2 3/4"
(70 mm)
6 1/4"
(159 mm)
5 5/16"
(135 mm)
2 3/4"
(70 mm)
RP73532▲ Pull-Up Diverter Channel Tub Spout
2 5/8"
(67 mm)
9"
(229 mm)
2"
(51 mm)
Square
