Technical data

136

- The brass housing hole is in the only category reported

below.

- The standard brass diameter after driving is variable on the

basis of a coupling selection.

- The brass seats into the crankcases are classified into 2 cate-

gories as for the driving shaft Cat. 1 and Cat. 2.

- Brasses are divided into 3 categories according to their thick-

ness. See the table below:

Match the shaft with two category 1 shoulders with category 1

crankcase (or cat. 2 with cat. 2).

A spare crankcase cannot be combined with a driving shaft with

mixed categories. Spare shafts have half-shafts of the same

category.

TYPE

IDENTIFICATION

RED

BLUE

YELLOW

Bench

halfbearing

Type “A”

1,970 ÷

1,973

Type “A” Type “A”

1,9703 ÷

1,976

1,976 ÷

1,979

Brass
