OVERHAUL
- Remove the spring clip shown in the picture.
- Suitably support the silencer mounting bracket.
- Using special tool, extract bearing from its housing as
shown in the picture.
Specific tooling
020376Y Handle for punches
020456Y 0 24 mm adaptor
- Using a heat gun, heat up the bearing housing.
- Using the special drift, insert a new bearing in the housing
as shown in the picture.
Specific tooling
020376Y Handle for punches
020151Y Air heater
REFITTING
- For the reassembly, follow the operations indicated above
in the reverse order, complying with the tightening torques.
Locking torques (N*m)
Rear wheel spindle nut 104 ÷ 126
Silencer support arm screws on engine (*) 20 ÷ 25
Shock absorber bottom fixing 33
÷ 41
