Specification

CONTACT SUPPORT
PHONE: [phone]
EMAIL: [e-mail]
ADDRESS: 8715 Boston place, Rancho Cucamonga, CA. 91730
www.designelementusa.com
• Avoid using any type of rough cleaning material on top of the cabinet
nish.
• Use mild liquid soap and water-dampened soft cloth to remove stains from
the cabinet and to clean the integrated sink countertop.
• For the glass part of the mirror, use ammonia-free cleaning products.
CLEANING AND CARE
SAFETY AND PRECAUTIONS
!
While turning around the double sink counter tops, always add
support from the centre for safety
!
While turning around the double sink counter tops, always add
support from the centre for safety
• Please go through this entire instruction manual before making any
attempt to assemble, operate or install the product.
• During installation, handle the integrated sink countertop with optimum
care. It might break if hit hard on a solid surface.
• Don’t start using the vanity right away. Wait for approximately 24 hours
after installation so that the silicon glue can dry.
•When scrubbing the cabinet while cleaning, make sure you do not remove
or scratch the nish.
1.
2.
3.
24h
1.
2.
3.
12"or 16"
1.
2.
3.
4.
2. Place the integrated sink on the glued cabinet.
3. Do not use the sink instantly. Wait approximately for 24 hours so that the silicon glue can dry.
1. Apply continuous stream of quality silicon glue to the top of the cabinet where the integrated sink needs to be placed.
Attaching Counter Top To Cabinet
3. Connect the trap onto the drain bottom.
2. Tie up the mounting rubbers and metal rings from the bottom of the drain.
1. After installing the counter top on the cabinet, put the drain assembly inside the hole in the sink and x it rmly.
Installing the drain
Hanging Mirror On The Wall
4. Hang the mirror on to the screws.
3. Insert the plastic plugs into the drilled holes and then insert screws into the plastic plugs. Tie up the screws till they
remain at least 0.5” – 0.75” outside the wall.
2. Locate the studs on the wall. They are normally placed 12” to 16” apart from each other. Drill two holes on the studs as
per your previous measurement.
1. Measure the distance between the screw holes from the back of the mirror.
PACKING LIST
• Pre-assembled cabinet
• Integrated sink countertop
• 1 Mirror
• Mirror mounting screws
• Drain
• Instruction Manual
WARRANTY
Design Element warrants cabinets, mirrors, nishes and ttings to be free
from defects in workmanship and materials under normal use and service
for a period of one (1) year.
Please report any damage or missing pieces of your vanity to us immedi-
ately. These things must be reported no later than 30 days from the date of
delivery.
BACK
FRONT
DEC016A
COLLECTION: Waterfall
DIMENSIONS: W 61” | D 17” | H 34”
SKU CODE:
INSTRUCTION MANUAL
DRAWER
17”
16 1/2”
61”
34”
36”
27”
59”
61”
10”
11”
12”
23”
23”
12”
17”
25”
22” 8”
7”
12”
7”
8”
17”
