Exploded Parts

Oakmont Single Handle Kitchen Faucet . SPARE PARTS
523225 523217
Satin Nickel Oil Rubbed Bronze
Order Code List Price Order Code List Price
1
Decorative Cap
2
Spout
3
Washer
4
Aeractor
5
Aeractor Shell
6
Wearable Ring
7
O-Ring
8
Pipe
9
Nut
10
O-Ring
11
Connector
12
O-Ring
13
Diverter
907584 $1.91 907584 $1.91
14
Body
15
Cartridge
907410 $7.71 907410 $7.71
16
Bonnect
17
Cap Seat
18
Handle Seat
19
Handle
20
Bolt
21
Srew
22
Decorative Cap
23
Decorative Cap
24
Flange
25
Washer
26
Crew
523225
No. Name
523217
909762 $5.40 909770 $6.08
11
10
09
08
07
06
05
04
03
02
01
26
Crew
27
Washer
28
Coupling Nut
29
O-Ring
30
Quick Connect Assembly
31
Block
32
O-Ring
33
O-Ring
34
Inlet Tube
35
Inlet Tube
36
Escutcheon
37
Base Plate
38
Side sprayer Assembly
11/23/2012 www. Todaysdesignhouse.com Design House is a registered brand name of DHI Corp.
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
21
22
20
19
18
17
16
15
14
13
12
