Specification

SERIES
INCLUDED
Standard Accessories Outstanding Features
TECHNICAL SPECIFICATIONS
17500 VERSIONS ALSO AVAILABLE.
3 VERSIONS:
www.warriorwinches.com
6
80SPS12
RATED LINE PULL: 8 000lbs (3629kg)
MOTOR: 12v : 4.6hp / 3.2kw
GEARING: 233:1
BRAKING ACTION: Auto in the drum
DRUM SIZE Dia x L: 2.5 x 8.8 inch
CABLE Dia x L: 0.3 inch x 85 ft
MOUNTING PATTERN: 10 x 4.5 inch
DIMENSIONS: 21.3 x 6.3 x 8.6 inch
95SPS12
RATED LINE PULL: 9500lbs (4500kg)
MOTOR: 12v : 4.6hp / 3.2kw
GEARING: 230:1
BRAKING ACTION: Auto in the drum
DRUM SIZE Dia x L: 2.5 x 8.8 inch
CABLE Dia x L: 0.36 inch x 82 ft
MOUNTING PATTERN: 10 x 4.5 inch
DIMENSIONS: 21.3 x 6.3 x 8.6 inch
12SPS12
RATED LINE PULL: 12 000lbs (5400kg)
MOTOR: 12v : 6.0hp / 4.6kw
GEARING: 230:1
BRAKING ACTION: Auto in the drum
DRUM SIZE Dia x L: 2.5 x 8.8 inch
CABLE Dia x L: 0.4 inch x 82 ft
MOUNTING PATTERN: 10 x 4.5 inch
DIMENSIONS: 22.8 x 6.3 x 8.6 inch
In the winching industry, you usually get what you pay for. The lower the price, the poorer the
quality. Very rarely is a new product brought to the market that is the exception to this rule,
giving you far more features & value than the price would imply. We are delighted to announce
the arrival of the Spartan Series, Tough, Strong and ready for a Battle, these Winches really
will challenge all before them. We have reluctantly termed them as ‘entry level’, however this
describes the price point, not the performance. We really believe these to be the best value for
money Winches around, a lower price does not mean that we have had to compromise the core
values integral to a good winch, such as reliability and durability.
• Galvanised steel cable
• 10ft Remote Handset
• Heavy Duty Steel Roller Fairlead
• Heavy Duty Battery Leads
• Stainless Steel Mounting hardware
• Clevis hook
• Weather Sealed High Performance motor
• Heavy-Duty 3 Stage Gearbox
• Heavy-Duty Drum Supports
• Weather Sealed Solenoids
• Full Steel Planetary Gearing
• Full Load Holding Brake
• Every winch 100 % load tested
• Chip Resistant Gloss Paint Finish
SPARTAN 12v Electric WinchES
‘Rise Up Warrior and
Take your Stand’
