HMI Panel Instruction Manual
SmartWireless HMI Panel Instruction Manual Rev. 1.0 Page 20 of 20
8.0 Spare Parts
Part Number Spare Parts
957-827280-032 SmartWireless HMI Panel in NEMA 7
327-000000-000 Programming Magnet
800-003648-000 Mounting Plate
976-000300-316 RXT-300 Wireless Transceiver
500-005143-100 Terminal Board
897-850902-010 NEMA 7 Tall Aluminum Condulet w/Window Cover
976-000303-012 12V Smart Battery Pack
960-202200-000 Condensation prevention packet (For condulet, replace annually)
897-044400-34T ¾” NPT T-Outlet Box w/Aluminum Cover
8522-750 ¾” NPT Plug
898-52310 ½” NPT Drain
899-07550 ¾” NPT to ½” NPT Adapter
899-15075 ¾” NPT x 1.5” Nipple
301-58205 ¾” NPT Cord Connector
Part Number Optional Accessories
976-000304-004 Quad Charger w/AC Adapter
976-0003FF-000 RXT Wireless Configuration Tool
9.0 Revision Log
Revision Date Changes made Approval
0.0 10/12/2011 Initial Release. LU
1.0 03/27/2012 Added N4X enclosure option (For RSM). LU
