• In order to delete a camera, select a camera from the list of existing cameras, and click on the
Delete button.
Cameras can be sorted in a camera list. To start the sorting process, double-click on the camera list header
(Fig. 11d) After double-clicking on the camera list, select any camera and move it up/down (Fig. 11.e.). To
save the sorted list, click on “Save cameras order” button (Fig. 11.e.)
To cancel the changes click “Cancel” (Fig. 11.e.).
2.b. Cameras Settings
Contains the following parameters that should be set:
• Camera name
• Type
• Address and address port
Select a non-standard port number if the camera is setup to listen to a non-standard port
Note: By default all cameras listen to port 80. In this case you can leave “0” in the field
• Proxy type
Internet access type, set to “Direct” if HTTP proxy is not used.
Some of the proxy types are listed bellow:
- Use Default
- Direct
- Named Proxy
- From the WEB
- Use as External Address
If a proxy is used, “Direct” method can also be used in most cases.
• Proxy address and Proxy port
Proxy address/port setups
• Flip Image
It is sometimes necessary for Sony cameras.
• With PTZ
• Check Alarm
Used by “Remote I/O Ports Listener”, if unchecked, “Remote listener” does not
check the status of inputs on this camera.
• Exclude from Recording
Recorder software uses this option. If checked, “Recorder” software
does not see this camera.
• Sound
This box needs to be checked if an Axis 2191 sound module is attached to camera.
• Stop touring while active
Stop touring if any client is trying to connect to camera.
• Restore for Recorder
Restore image settings for camera, if client has changed it.
• Image size: initial size of images when connection to camera has been established.
• Max FPS on write
• Max FPS on Request
• Images path for FTP server
This setting is used for
FTP Server only. Should be unique for each camera
It must have the same setting as “FTP Directory” path inside the camera (camera that
is FTP-ing images).
• Position on close
Used for JVC Cameras, returns camera to one of the preset positions (if setup) upon
leaving the camera.
