User guide

NVR
32
New → “Action”
4.a. Record Camera
Fig. 22. New → Action →Record Camera
Action (Record Camera) Setup:
• Camera: Select a camera for this action.
• Set camera in position
- Pan/ Tilt/ Zoom
- Or Preset
• Record
- Image size
- Compression
- FPS
- Frames
- Sec.
• Take Alarm shot: For PTZ cameras; if checked, takes alarm shots.
• Delay (ms): Since actions and notifications in a task take place simultaneously, camera could be
pointing in any direction other than the region that alarm shot should be taken from; thus a very
small delay time might be required to assure uniformity of task execution.
• Reset camera in position
-
Pan/ Tilt/ Zoom
-
Or Preset
•
Connect/Stop: When camera is selected, click on connect button in order to connect to that
camera (click on stop button to disconnect from the selected camera).
•
Show Locally
•
Uninterruptable alarm
•
Use local connection
Click here to
bring up PTZ
control
dialogue box
