User guide

NVR

• Pan/ Tilt/ Zoom

• Get PTZ: When clicked, provides the PTZ value of the position that camera is pointing to.

• Set PTZ: Can be used in order to change PTZ values.

• Zoom IN/OUT

• Go to Preset: Choose a preset position from the pull down menu and click on “Go to Preset”; as a

result camera will point to the selected preset position.

• Home position

• Direction control tool: Can be used to control the direction of the camera towards Right, Left,

Up, and Down.

4.c. Control Relay

Fig. 25. New → Action →Control Relay

Action (Control Relay) Setup:

• Relay: An output that can be selected from the pull down menu (e.g. light).

• Turn On: If checked, the selected output turns on.

• Turn Off: If checked, the selected output turns off.

• Activate

• Dwell time(s): the time in which the selected output (e.g. light) stays on/off.

• Reset relay: If checked, resets relay to its previous state.

e.g. 5 sec.
