® DW955(K) DW965(K) DW966(K)
Dansk 1 Deutsch 7 English 14 Español 21 Français 28 Italiano 35 Nederlands 42 Norsk 49 Português 55 Suomi 62 Svenska 68 Türkçe 74 EÏÏËÓÈη 81 Copyright DEWALT
5 3 4 1 2 6 6 7 8 9 A
3 B 10 C
D
ENGLISH CORDLESS RIGHT ANGLE DRILL DW955/DW965/DW966 Congratulations! You have chosen a DEWALT Power Tool. Years of experience, thorough product development and innovation make DEWALT one of the most reliable partners for professional Power Tool users. Table of contents Technical data EC-Declaration of conformity Safety instructions Package contents Description Electrical safety Mains plug replacement (U.K.
ENGLISH LpA (sound pressure) LWA (acoustic power) DW955 DW965 DW966 dB(A)* 70 70 70 dB(A) 85 85 85 * at the operator’s ear Take appropriate measures for the protection of hearing if the sound pressure of 85 dB(A) is exceeded. Weighted root mean square acceleration value according to EN 50144: DW955 DW965 DW966 < 2.5 m/s2 < 2.5 m/s2 < 2.
ENGLISH an authorized DEWALT repair agent. Keep all controls dry, clean and free from oil and grease. 15 Check for damaged parts Before using the tool, carefully check it for damage to ensure that it will operate properly and perform its intended function. Check for misalignment and seizure of moving parts, breakage of parts and any other conditions that may affect its operation. Have damaged guards or other defective parts repaired or replaced as instructed. Do not use the tool if the switch is defective.
ENGLISH • Take the time to thoroughly read and understand this manual prior to operation. Description (fig. A) • Before replacing the top cover of the mains plug ensure that the cable restraint (3) is holding the outer sheath of the cable firmly and that the two leads are correctly fixed at the terminal screws. Your cordless right angle drill has been designed for professional drilling and screwdriving applications, especially in confined spaces.
ENGLISH Do not charge the battery pack at ambient temperatures <4 °C or >40 °C. Recommended charging temperature: approx. 24 °C. • To charge the battery pack (6), insert it into the charger (8) as shown and plug in the charger. Be sure that the battery pack is fully seated in the charger. The red charging indicator (9) will blink. After approx. 1 hour, it will stop blinking and remain on. The battery pack is now fully charged.
ENGLISH The drill is equipped with a brake to stop the tool as soon as the variable speed switch is fully released. Drilling in metal • Use a cutting lubricant when drilling metals. The exceptions are cast iron and brass which should be drilled dry. Drilling in wood • Holes in wood can be made with the same twist drills used for metal. These bits may overheat unless pulled out frequently to clear chips from the flutes. • For larger holes use Auger bits.
ENGLISH GUARANTEE • 30 DAY NO RISK SATISFACTION GUARANTEE • If you are not completely satisfied with the performance of your DEWALT tool, simply return it within 30 days, complete as purchased, to the point of purchase, for a full refund or exchange. Proof of purchase must be produced. • ONE YEAR FREE SERVICE CONTRACT • If you need maintenance or service for your DEWALT tool, in the 12 months following purchase, it will be undertaken free of charge at an authorized DEWALT repair agent.
