94
6 Message Reference
6.6.4 QSL_MSG_END_LINK – Remove Q.SAAL Link
Synopsis
Remove a Q.SAAL Link - only allowed when the link is in the inactive state.
Message Format
Description
Sent by the user to deactivate a link, remove its connection from the underling ATM cell stream and release
its resources.
• link_id
Identifier for this link.
MESSAGE HEADER
Field Name Meaning
type QSL_MSG_END_LINK (0x7269)
id Link ID
src User Module ID
dst QSL_TASK_ID
rsp_req Used to request a confirmation
hclass 0
status 0
err_info 0
len 0
