Corporation Personal Computer User Manual

PegasusFastStartGuide
DSCDocument#7460572RevA
Pegasusisarugged,low‐powerPC/104‐PlusSingleBoardComputer(SBC)witha500MHzAMDLX800
CPU,256MBofon‐boardDRAMandanoptional2GBon‐boardIDEflashdisk.

ThisFastStartGuideprovidesanoverviewofPegasus’features,alistingofproducts,information onthe
I/Oconnectionsandjumperson‐board,BIOSandIDEconsiderations,andabasicprocedureforpowering
uptheSBC.FormoredetailedinformationpleaserefertothePegasusUserManual.




PEGASUSKEYFEATURES

♦ Lowpower,mid‐rangePC/104‐Plusexpandablesingleboardcomputer
♦ AMDGeodeLX800processoroperatingfan‐lessat500MHz
♦ 256MBDDRDRAMsolderedon‐board
♦ 2GBon‐boardIDEflashdisk(modelPGS800‐256‐2Gonly)
♦ Fullyfeaturedincludingsupportfor:
o FourUSB2.0ports
o OneRS‐232serialport
o OneRS‐232/422/485serialport
o 10/100MbpsEthernet
o IDEharddriveinterfaceforonedevice
o TypeIICompactFlashsocket
o VGACRTand1280X1024LCD
o PS/2KeyboardandMouse
♦ SupportforWindowsXP,WindowsXPe,WindowsCE,Linux,andDOS
♦ PC/104‐Plus(ISA+PCI)stackthroughexpansion
♦ ‐40°Cto+85°Coperatingtemperature

PRODUCTMODELNUMBERS

Model Description
PGS800‐256‐2G PegasusSBC,500MHzLX800,256MBon‐boardDRAM,2GBon‐boardIDEflashdisk
PGS800‐256 PegasusSBC,500MHzLX800,256MBon‐boardDRAM,noon‐boardIDEflashdisk
C‐PGS‐KIT PegasusCableKit
