Configuration Settings 17
31 PC/PRN Output Data Method
0: No operation
1: Counting
2: By +/-/Print Key (PC/PRN) (DEFAULT)
3: For both classes 1 & 2
32 Select External Printer Type
0: Eltron/TVP (DEFAULT)
1: SE520
2: DP122 (Japan)
3: Epson
33 External Eltron/TVP Printer Download Label Format
0: Enable (DEFAULT)
1: Disable
34 Print When Press +/- Key
0: Disable (DEFAULT)
1: Enable
35 PC Data With Header
0: Yes (DEFAULT)
1: No
36 PC Data Header Type
0: Code 9 - numeric headers (DEFAULT)
1: Title - alphabetic headers
37 IBM Keyboard Port
0: IBM Keyboard
1: Barcode Scanner
38 Barcode Scanner (BCS) With Header
0: Yes (DEFAULT)
1: No
39 Track Nprint (TNP) Time Out
0: 2 seconds (DEFAULT)
1: 8 seconds
2: 32 seconds
40-49 SPEC 40-49 are not used by the DC-100.
50 Selection of Label and Receipt Printing Operation
0: All operation (in/out/non-add) (DEFAULT)
1: Out (shipping operations)
2: In (receiving operations)
3: In and out
4: No printing
51-58 SPEC 51-58 are not used by the DC-100
59 Selection of Barcode Type
0: Code 128A
1: Code 128B
2: EAN 128A
3: EAN 128B
4: CODE 39 (DEFAULT)
60 Auto Print Function
0: Between set point 1 and set point 2
1: Disable (DEFAULT)
61 Not used by the DC-100
SPEC Description
Table 3-1. DC-100 (141) Settings
