6.0 Scale Programming
The DC-100 can store information for the parts you count most frequently, eliminating the need for re-entering
data during parts counting. With up to 2,000 item code numbers able to be programmed into your
420 Plus
counting scale, the scale can act as a stand-alone inventory system.
6.1 Item Code Storage
Before beginning to enter data about an item, you need to have defined ahead of time the setpoints you are going
to attach to this particular item
See Section 6.1.2 on page 37 .
Table 6-1. Teraoka Codes
When entering data on the 420 Plus, you can use the following functions of the keyboard:
SPACE A B C D E F G H I
00 01 02 03 04 05 06 07 08 09
J K L M N O P Q R S
10 11 12 13 14 15 16 17 18 19
T U V W X Y Z , . -
20 21 22 23 24 25 26 27 28 29
0 1 2 3 4 5 6 7 8 9
30 31 32 33 34 35 36 37 38 39
@ ! “ # $ % & / ( )
40 41 42 42 44 45 46 47 48 49
‘ < > + : * À Â È Ê
50 58 59 69 72 73 77 78 79 80
É Ô Ç ? → ←
81 82 83 96 97 98
Key Description
To move the cursor to change the entry to the right
To move the cursor to change the entry to the left
To delete the character to the left of the cursor
Table 6-2. Item Storage Function Code Keys
