Introduction 3
1.2 Modes of Operation
1.2.1 Description of Modes of Operation
• Operation Mode – where all the basic weighing and counting operations are performed (also called the
Registration Mode).
• Report Mode – the report mode is not used in the DC-100
• Program Mode –where item data, factory name, and other data can be programmed into the memory of
the scale.
• Password Mode – where you can set passwords that will be required for a scale operator to use certain
functions of the scale.
A fifth mode of operation, Service Mode, is used by your DIGI Dealer or authorized service technician to
perform initial programming and troubleshooting operations.
Which mode you are in is displayed on the right-hand side of the display panel by the following codes:
Mode Annunciator
Operation Mode Default mode, no letter displayed
Report Mode X
Program Mode S
Password Mode The code for the mode you are password protecting is displayed
Service Mode Z
Table 1-3. DC-100 Modes of Operation
