4 Quad SPI Flash
The Arty Z7 features a Quad SPI serial NOR flash. The Spansion S25FL128S is used on this
board. The Multi-I/O SPI Flash memory is used to provide non-volatile code and data storage. It
can be used to initialize the PS subsystem as well as configure the PL subsystem.
The relevant device attributes are:
16 MB
x1, x2, and x4 support
Bus speeds up to 104 MHz, supporting Zynq configuration rates @ 100 MHz. In Quad
SPI mode, this translates to 400Mbs
Powered from 3.3V
The SPI Flash connects to the Zynq-7000 APSoC and supports the Quad SPI interface. This
requires connection to specific pins in MIO Bank 0/500, specifically MIO[1:6,8] as outlined in
the Zynq datasheet. Quad-SPI feedback mode is used, thus qspi_sclk_fb_out/MIO[8] is left to
freely toggle and is connected only to a 20K pull-up resistor to 3.3V. This allows a Quad SPI
clock frequency greater than FQSPICLK2 (See the Zynq Technical Reference manual for more
on this).
5 DDR Memory
The Arty Z7 includes an IS43TR16256A-125KBL DDR3 memory components creating a single
rank, 16-bit wide interface and a total of 512MiB of capacity. The DDR3 is connected to the
hard memory controller in the Processor Subsystem (PS), as outlined in the Zynq documentation.
The PS incorporates an AXI memory port interface, a DDR controller, the associated PHY, and a
dedicated I/O bank. DDR3 memory interface speeds up to 533 MHz/1066 Mbps are supported¹.
Arty Z7 was routed with 40 ohm (+/-10%) trace impedance for single-ended signals, and
differential clock and strobes set to 80 ohms (+/-10%). A feature called DCI (Digitally
Controlled Impedance) is used to match the drive strength and termination impedance of the PS
pins to the trace impedance. On the memory side, each chip calibrates its on-die termination and
drive strength using a 240 ohm resistor on the ZQ pin.
Due to layout reasons, the two data byte groups (DQ[0-7], DQ[8-15]) were swapped. To the
same effect, the data bits inside byte groups were swapped as well. These changes are
transparent to the user. During the whole design process the Xilinx PCB guidelines were
followed.
