The PL is nearly identical to a Xilinx 7-series Artix FPGA, except that it contains several
dedicated ports and buses that tightly couple it to the PS. The PL also does not contain the same
configuration hardware as a typical 7-series FPGA, and it must be configured either directly by
the processor or via the JTAG port.
The PS consists of many components, including the Application Processing Unit (APU, which
includes 2 Cortex-A9 processors), Advanced Microcontroller Bus Architecture (AMBA)
Interconnect, DDR3 Memory controller, and various peripheral controllers with their inputs and
outputs multiplexed to 54 dedicated pins (called Multiplexed I/O, or MIO pins). Peripheral
controllers that do not have their inputs and outputs connected to MIO pins can instead route
their I/O through the PL, via the Extended-MIO (EMIO) interface. The peripheral controllers are
connected to the processors as slaves via the AMBA interconnect, and contain readable/writable
control registers that are addressable in the processors’ memory space. The programmable logic
is also connected to the interconnect as a slave, and designs can implement multiple cores in the
FPGA fabric that each also contain addressable control registers. Furthermore, cores
implemented in the PL can trigger interrupts to the processors (connections not shown in Fig. 3)
and perform DMA accesses to DDR3 memory.
There are many aspects of the Zynq APSoC architecture that are beyond the scope of this
document. For a complete and thorough description, refer to the Zynq Technical Reference
manual.
Table 2.1 depicts the external components connected to the MIO pins of the Arty Z7. The Zynq
Presets File found on the Arty Z7 Resource Center can be imported into EDK and Vivado
Designs to properly configure the PS to work with these peripherals.
MIO 500 3.3 V Peripherals
Pin ENET 0 SPI Flash USB 0 Shield UART 0
0 (N/C)
1 CS
2 DQ0
3 DQ1
4 DQ2
5 DQ3
6 SCLK
7 (N/C)
8 SLCK FB
9 Ethernet Reset
10 Ethernet Interrupt
11
USB Over
Current
12 Shield
