Table 2.1. MIO Pinout

3 Zynq Configuration

Unlike Xilinx FPGA devices, APSoC devices such as the Zynq-7020 are designed around the

processor, which acts as a master to the programmable logic fabric and all other on-chip

peripherals in the processing system. This causes the Zynq boot process to be more similar to

that of a microcontroller than an FPGA. This process involves the processor loading and

executing a Zynq Boot Image, which includes a First Stage Bootloader (FSBL), a bitstream for

configuring the programmable logic (optional), and a user application. The boot process is

broken into three stages:

Stage 0

After the Arty Z7 is powered on or the Zynq is reset (in software or by pressing SRST), one of

the processors (CPU0) begins executing an internal piece of read-only code called the

BootROM. If and only if the Zynq was just powered on, the BootROM will first latch the state of

the mode pins into the mode register (the mode pins are attached to JP4 on the Arty Z7). If the

BootROM is being executed due to a reset event, then the mode pins are not latched, and the

previous state of the mode register is used. This means that the Arty Z7 needs a power cycle to

FSBL from the form of non-volatile memory specified by the mode register to the 256 KB of

internal RAM within the APU (called On-Chip Memory, or OCM). The FSBL must be wrapped

up in a Zynq Boot Image in order for the BootROM to properly copy it. The last thing the

BootROM does is hand off execution to the FSBL in OCM.
