Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1003
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (dap) ROMENTRY00
Register ROMENTRY00 Details
Register (dap) ROMENTRY01
COMPID0 0x00000FF0 8 ro 0x0000000D Component ID0
COMPID1
0x00000FF4 8 ro 0x00000010 Component ID1
COMPID2
0x00000FF8 8 ro 0x00000005 Component ID2
COMPID3
0x00000FFC 8 ro 0x000000B1 Component ID3
Name ROMENTRY00
Relative Address 0x00000000
Absolute Address 0xF8800000
Width 32 bits
Access Type ro
Reset Value 0x00001003
Description ROM entry 00
Register Name Address Width Type Reset Value Description
Field Name Bits Type Reset Value Description
AddressOffset 31:12 ro 0x1 Base address of the component, relative to the
ROM address.
Negative values are permitted using two's
complement.
ComponentAddress = ROMAddress +
(AddressOffset SHL 12)
reserved 11:2 ro 0x0 Reserved
Format 1 ro 0x1 Format of ROM entry
Enumerated Value List:
32BIT=1.
8BIT=0.
EntryPresent 0 ro 0x1 Set HIGH to indicate an entry is present.
Name ROMENTRY01
Relative Address 0x00000004
Absolute Address 0xF8800004
Width 32 bits
Access Type ro
