Appendix B: Register Details
Register (dap) ROMENTRY03
Register ROMENTRY03 Details
Register (dap) ROMENTRY04
Format 1 ro 0x1 Format of ROM entry
Enumerated Value List:
32BIT=1.
8BIT=0.
EntryPresent 0 ro 0x1 Set HIGH to indicate an entry is present.
Name ROMENTRY03
Relative Address 0x0000000C
Absolute Address 0xF880000C
Width 32 bits
Access Type ro
Reset Value 0x00004003
Description ROM entry 03
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
AddressOffset 31:12 ro 0x4 Base address of the component, relative to the
ROM address.
Negative values are permitted using two's
complement.
ComponentAddress = ROMAddress +
(AddressOffset SHL 12)
reserved 11:2 ro 0x0 Reserved
Format 1 ro 0x1 Format of ROM entry
Enumerated Value List:
32BIT=1.
8BIT=0.
EntryPresent 0 ro 0x1 Set HIGH to indicate an entry is present.
Name ROMENTRY04
Relative Address 0x00000010
Absolute Address 0xF8800010
Width 32 bits
Access Type ro
