Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1007
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (dap) ROMENTRY06
Register ROMENTRY06 Details
Register (dap) ROMENTRY07
Format 1 ro 0x1 Format of ROM entry
Enumerated Value List:
32BIT=1.
8BIT=0.
EntryPresent 0 ro 0x1 Set HIGH to indicate an entry is present.
Name ROMENTRY06
Relative Address 0x00000018
Absolute Address 0xF8800018
Width 32 bits
Access Type ro
Reset Value 0x0000A003
Description ROM entry 06
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
AddressOffset 31:12 ro 0xA Base address of the component, relative to the
ROM address.
Negative values are permitted using two's
complement.
ComponentAddress = ROMAddress +
(AddressOffset SHL 12)
reserved 11:2 ro 0x0 Reserved
Format 1 ro 0x1 Format of ROM entry
Enumerated Value List:
32BIT=1.
8BIT=0.
EntryPresent 0 ro 0x1 Set HIGH to indicate an entry is present.
Name ROMENTRY07
Relative Address 0x0000001C
Absolute Address 0xF880001C
Width 32 bits
Access Type ro
