Appendix B: Register Details
Register ROMENTRY07 Details
Register (dap) ROMENTRY08
Register ROMENTRY08 Details
Reset Value 0x0000B003
Description ROM entry 07
Field Name Bits Type Reset Value Description
AddressOffset 31:12 ro 0xB Base address of the component, relative to the
ROM address.
Negative values are permitted using two's
complement.
ComponentAddress = ROMAddress +
(AddressOffset SHL 12)
reserved 11:2 ro 0x0 Reserved
Format 1 ro 0x1 Format of ROM entry
Enumerated Value List:
32BIT=1.
8BIT=0.
EntryPresent 0 ro 0x1 Set HIGH to indicate an entry is present.
Name ROMENTRY08
Relative Address 0x00000020
Absolute Address 0xF8800020
Width 32 bits
Access Type ro
Reset Value 0x0000C003
Description ROM entry 08
Field Name Bits Type Reset Value Description
AddressOffset 31:12 ro 0xC Base address of the component, relative to the
ROM address.
Negative values are permitted using two's
complement.
ComponentAddress = ROMAddress +
(AddressOffset SHL 12)
reserved 11:2 ro 0x0 Reserved
