Appendix B: Register Details
Register (dap) ROMENTRY13
Register ROMENTRY13 Details
Register (dap) ROMENTRY14
Register ROMENTRY14 Details
Register (dap) ROMENTRY15
Name ROMENTRY13
Relative Address 0x00000034
Absolute Address 0xF8800034
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description ROM entry 13
Field Name Bits Type Reset Value Description
31:0 rw 0x0 Invalid entry
Name ROMENTRY14
Relative Address 0x00000038
Absolute Address 0xF8800038
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description ROM entry 14
Field Name Bits Type Reset Value Description
31:0 rw 0x0 Invalid entry
Name ROMENTRY15
Relative Address 0x0000003C
Absolute Address 0xF880003C
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description ROM entry 15
