Appendix B: Register Details
Register ROMENTRY15 Details
Register (dap) PERIPHID4
Register PERIPHID4 Details
Register (dap) PERIPHID5
Register PERIPHID5 Details
Register (dap) PERIPHID6
Field Name Bits Type Reset Value Description
31:0 rw 0x0 Invalid entry
Name PERIPHID4
Relative Address 0x00000FD0
Absolute Address 0xF8800FD0
Width 8 bits
Access Type ro
Reset Value 0x00000003
Description Peripheral ID4
Field Name Bits Type Reset Value Description
4KB_count 7:4 ro 0x0 4KB Count, set to 0
3:0 ro 0x3 JEP106 continuation code
Name PERIPHID5
Relative Address 0x00000FD4
Absolute Address 0xF8800FD4
Width 8 bits
Access Type ro
Reset Value 0x00000000
Description Peripheral ID5
Field Name Bits Type Reset Value Description
reserved 7:0 ro 0x0 Reserved
Name PERIPHID6
