Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1014
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register PERIPHID0 Details
Register (dap) PERIPHID1
Register PERIPHID1 Details
Register (dap) PERIPHID2
Register PERIPHID2 Details
Field Name Bits Type Reset Value Description
PartNumber0 7:0 ro 0xB2 PartNumber0
Name PERIPHID1
Relative Address 0x00000FE4
Absolute Address 0xF8800FE4
Width 8 bits
Access Type ro
Reset Value 0x00000093
Description Peripheral ID1
Field Name Bits Type Reset Value Description
JEP106ID 7:4 ro 0x9 JEP106 Identity Code [3:0]
PartNumber1 3:0 ro 0x3 PartNumber1
Name PERIPHID2
Relative Address 0x00000FE8
Absolute Address 0xF8800FE8
Width 8 bits
Access Type ro
Reset Value 0x00000028
Description Peripheral ID2
Field Name Bits Type Reset Value Description
RevNum 7:4 ro 0x2 Revision number of Peripheral
JEDEC 3 ro 0x1 Indicates that a JEDEC assigned value is used
JEP106ID 2:0 ro 0x0 JEP106 Identity Code [6:4]
