Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1015
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (dap) PERIPHID3
Register PERIPHID3 Details
Register (dap) COMPID0
Register COMPID0 Details
Register (dap) COMPID1
Name PERIPHID3
Relative Address 0x00000FEC
Absolute Address 0xF8800FEC
Width 8 bits
Access Type ro
Reset Value 0x00000007
Description Peripheral ID3
Field Name Bits Type Reset Value Description
RevAnd 7:4 ro 0x0 RevAnd, at top level
CustMod 3:0 ro 0x7 Customer Modified
Name COMPID0
Relative Address 0x00000FF0
Absolute Address 0xF8800FF0
Width 8 bits
Access Type ro
Reset Value 0x0000000D
Description Component ID0
Field Name Bits Type Reset Value Description
Preamble 7:0 ro 0xD Preamble
Name COMPID1
Relative Address 0x00000FF4
Absolute Address 0xF8800FF4
Width 8 bits
Access Type ro
Reset Value 0x00000010
