Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1016
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register COMPID1 Details
Register (dap) COMPID2
Register COMPID2 Details
Register (dap) COMPID3
Register COMPID3 Details
Description Component ID1
Field Name Bits Type Reset Value Description
Preamble 7:0 ro 0x10 Preamble
Name COMPID2
Relative Address 0x00000FF8
Absolute Address 0xF8800FF8
Width 8 bits
Access Type ro
Reset Value 0x00000005
Description Component ID2
Field Name Bits Type Reset Value Description
Preamble 7:0 ro 0x5 Preamble
Name COMPID3
Relative Address 0x00000FFC
Absolute Address 0xF8800FFC
Width 8 bits
Access Type ro
Reset Value 0x000000B1
Description Component ID3
Field Name Bits Type Reset Value Description
Preamble 7:0 ro 0xB1 Preamble
