Appendix B: Register Details
Register FFSR Details
Register (etb) FFCR
Register FFCR Details
Relative Address 0x00000300
Absolute Address 0xF8801300
Width 2 bits
Access Type ro
Reset Value 0x00000002
Description Formatter and Flush Status Register
Field Name Bits Type Reset Value Description
FtStopped 1 ro 0x1 Formatter stopped. The formatter has received a
stop request signal and all trace data and
post-amble has been output. Any more trace data
on the ATB interface is ignored and ATREADYS
goes HIGH.
FlInProg 0 ro 0x0 Flush In Progress. This is an indication of the
current state of AFVALIDS.
Name FFCR
Relative Address 0x00000304
Absolute Address 0xF8801304
Width 14 bits
Access Type mixed
Reset Value 0x00000200
Description Formatter and Flush Control Register
Field Name Bits Type Reset Value Description
StopTrig 13 rw 0x0 Stop the formatter when a Trigger Event has been
observed.
StopFl 12 rw 0x0 Stop the formatter when a flush has completed
(return of AFREADYS). This forces the FIFO to
drain off any part-completed packets. Setting this
bit enables this function but this is clear on reset
(disabled).
reserved 11 ro 0x0 Reserved
TrigFl 10 rw 0x0 Indicate a trigger on Flush completion
(AFREADYS being returned).
TrigEvt 9 rw 0x1 Indicate a trigger on a Trigger Event.
