Appendix B: Register Details
Register (etb) ITTRFLINACK
Register ITTRFLINACK Details
Register (etb) ITTRFLIN
Register ITTRFLIN Details
Register (etb) ITATBDATA0
Name ITTRFLINACK
Relative Address 0x00000EE4
Absolute Address 0xF8801EE4
Width 2 bits
Access Type wo
Reset Value 0x00000000
Description Integration Test Trigger In and Flush In Acknowledge Register
Field Name Bits Type Reset Value Description
FLUSHINACK 1 wo 0x0 Set the value of FLUSHINACK
TRIGINACK 0 wo 0x0 Set the value of TRIGINACK
Name ITTRFLIN
Relative Address 0x00000EE8
Absolute Address 0xF8801EE8
Width 2 bits
Access Type wo
Reset Value 0x00000000
Description Integration Test Trigger In and Flush In Register
Field Name Bits Type Reset Value Description
FLUSHIN 1 wo 0x0 Read the value of FLUSHIN
TRIGIN 0 wo 0x0 Read the value of TRIGIN
Name ITATBDATA0
Relative Address 0x00000EEC
Absolute Address 0xF8801EEC
Width 5 bits
Access Type ro
