Appendix B: Register Details
Register ITATBDATA0 Details
Register (etb) ITATBCTR2
Register ITATBCTR2 Details
Register (etb) ITATBCTR1
Reset Value 0x00000000
Description Integration Test ATB Data Register
Field Name Bits Type Reset Value Description
ATDATA31 4 ro 0x0 Read the value of ATDATA[31]
ATDATA23 3 ro 0x0 Read the value of ATDATA[23]
ATDATA15 2 ro 0x0 Read the value of ATDATA[15]
ATDATA7 1 ro 0x0 Read the value of ATDATA[7]
ATDATA0 0 ro 0x0 Read the value of ATDATA[0]
Name ITATBCTR2
Relative Address 0x00000EF0
Absolute Address 0xF8801EF0
Width 2 bits
Access Type wo
Reset Value 0x00000000
Description Integration Test ATB Control Register 2
Field Name Bits Type Reset Value Description
AFVALIDS 1 wo 0x0 Set the value of AFVALIDS
ATREADYS 0 wo 0x0 Set the value of ATREADYS
Name ITATBCTR1
Relative Address 0x00000EF4
Absolute Address 0xF8801EF4
Width 7 bits
Access Type ro
Reset Value 0x00000000
Description Integration Test ATB Control Register 1
