Appendix B: Register Details
Register ITATBCTR1 Details
Register (etb) ITATBCTR0
Register ITATBCTR0 Details
Register (etb) IMCR
Register IMCR Details
Field Name Bits Type Reset Value Description
ATID 6:0 ro 0x0 Read the value of ATIDS
Name ITATBCTR0
Relative Address 0x00000EF8
Absolute Address 0xF8801EF8
Width 10 bits
Access Type ro
Reset Value 0x00000000
Description Integration Test ATB Control Register 0
Field Name Bits Type Reset Value Description
ATBYTES 9:8 ro 0x0 Read the value of ATBYTES
reserved 7:2 ro 0x0 Reserved
AFREADY 1 ro 0x0 Read the value of AFREADYS
ATVALID 0 ro 0x0 Read the value of ATVALIDS
Name IMCR
Relative Address 0x00000F00
Absolute Address 0xF8801F00
Width 1 bits
Access Type rw
Reset Value 0x00000000
Description Integration Mode Control Register
Field Name Bits Type Reset Value Description
0 rw 0x0 Enable Integration Test registers.
