Appendix B: Register Details
Register (etb) CTSR
Register CTSR Details
Register (etb) CTCR
Register CTCR Details
Name CTSR
Relative Address 0x00000FA0
Absolute Address 0xF8801FA0
Width 4 bits
Access Type rw
Reset Value 0x0000000F
Description Claim Tag Set Register
Field Name Bits Type Reset Value Description
3:0 rw 0xF The claim tag register is used for any
interrogating tools to determine if the device is
being programmed or has been programmed.
Read:
1= Claim tag is implemented, 0 = Claim tag is not
implemented
Write:
1= Set claim tag bit, 0= No effect
Name CTCR
Relative Address 0x00000FA4
Absolute Address 0xF8801FA4
Width 4 bits
Access Type rw
Reset Value 0x00000000
Description Claim Tag Clear Register
Field Name Bits Type Reset Value Description
3:0 rw 0x0 The claim tag register is used for any
interrogating tools to determine if the device is
being programmed or has been programmed.
Read: Current value of claim tag.
Write: 1= Clear claim tag bit, 0= No effect
