Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1037
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
B.12 PL Fabric Trace Monitor (ftm)
Register Summary
Module Name PL Fabric Trace Monitor (ftm)
Base Address 0xF880B000 debug_ftm
Description Fabric Trace Macrocell
Vendor Info
Register Name Address Width Type Reset Value Description
FTMGLBCTRL
0x00000000 1 rw 0x00000000 FTM Global Control Register
FTMSTATUS
0x00000004 8 ro 0x00000082 FTM Status Register
FTMCONTROL
0x00000008 3 rw 0x00000000 FTM Configuration
FTMP2FDBG0
0x0000000C 8 rw 0x00000000 FPGA Debug Register P2F0
FTMP2FDBG1
0x00000010 8 rw 0x00000000 FPGA Debug Register P2F1
FTMP2FDBG2
0x00000014 8 rw 0x00000000 FPGA Debug Register P2F2
FTMP2FDBG3
0x00000018 8 rw 0x00000000 FPGA Debug Register P2F3
FTMF2PDBG0
0x0000001C 8 ro 0x00000000 FPGA Debug Register F2P0
FTMF2PDBG1
0x00000020 8 ro 0x00000000 FPGA Debug Register F2P1
FTMF2PDBG2
0x00000024 8 ro 0x00000000 FPGA Debug Register F2P2
FTMF2PDBG3
0x00000028 8 ro 0x00000000 FPGA Debug Register F2P3
CYCOUNTPRE
0x0000002C 4 rw 0x00000000 AXI Cycle Count clock
pre-scaler
FTMSYNCRELOAD
0x00000030 12 rw 0x00000000 FTM Synchronization Counter
reload value
FTMSYNCCOUT
0x00000034 12 ro 0x00000000 FTM Synchronization Counter
value
FTMATID
0x00000400 7 rw 0x00000000 FTM ATID Value Register
FTMITTRIGOUTACK
0x00000ED0 4 ro 0x00000000 Trigger Output Acknowledge
Integration Test Register
FTMITTRIGGER
0x00000ED4 4 wo 0x00000000 Trigger Output Integration Test
Register
FTMITTRACEDIS
0x00000ED8 1 ro 0x00000000 External Trace Disable
Integration Test Register
FTMITCYCCOUNT
0x00000EDC 32 rw 0x00000001 Cycle Counter Test Register
FTMITATBDATA0
0x00000EEC 5 wo 0x00000000 ATB Data Integration Test
Register 0
