Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1042
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register FTMP2FDBG3 Details
Register (ftm) FTMF2PDBG0
Register FTMF2PDBG0 Details
Register (ftm) FTMF2PDBG1
Register FTMF2PDBG1 Details
Field Name Bits Type Reset Value Description
PSS2FPGA 7:0 rw 0x0 Signals presented to the fabric. These signals do
not affect the FTM, they are provided for user
specific debug. To modify the contents of this
register, the SPIDEN pin must be asserted.
Name FTMF2PDBG0
Relative Address 0x0000001C
Absolute Address 0xF880B01C
Width 8 bits
Access Type ro
Reset Value 0x00000000
Description FPGA Debug Register F2P0
Field Name Bits Type Reset Value Description
FPGA2PSS 7:0 ro 0x0 Signals that are presented to the PSS from the
Fabric.
Name FTMF2PDBG1
Relative Address 0x00000020
Absolute Address 0xF880B020
Width 8 bits
Access Type ro
Reset Value 0x00000000
Description FPGA Debug Register F2P1
Field Name Bits Type Reset Value Description
FPGA2PSS 7:0 ro 0x0 Signals that are presented to the PSS from the
Fabric.
