Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1054
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register FTMPERIPHID7 Details
Register (ftm) FTMPERIPHID0
Register FTMPERIPHID0 Details
Register (ftm) FTMPERIPHID1
Relative Address 0x00000FDC
Absolute Address 0xF880BFDC
Width 8 bits
Access Type ro
Reset Value 0x00000000
Description Peripheral ID7
Field Name Bits Type Reset Value Description
reserved 7:0 ro 0x0 Reserved
Name FTMPERIPHID0
Relative Address 0x00000FE0
Absolute Address 0xF880BFE0
Width 8 bits
Access Type ro
Reset Value 0x00000001
Description Peripheral ID0
Field Name Bits Type Reset Value Description
PARTNUMLOWER 7:0 ro 0x1 Part Number Lower
Name FTMPERIPHID1
Relative Address 0x00000FE4
Absolute Address 0xF880BFE4
Width 8 bits
Access Type ro
Reset Value 0x00000090
Description Peripheral ID1
