Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1055
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register FTMPERIPHID1 Details
Register (ftm) FTMPERIPHID2
Register FTMPERIPHID2 Details
Register (ftm) FTMPERIPHID3
Register FTMPERIPHID3 Details
Field Name Bits Type Reset Value Description
JEP106 7:4 ro 0x9 JEP106 identity bits [3:0]
PARTNUMUPPER 3:0 ro 0x0 Part Number Upper [11:8]
Name FTMPERIPHID2
Relative Address 0x00000FE8
Absolute Address 0xF880BFE8
Width 8 bits
Access Type ro
Reset Value 0x0000000C
Description Peripheral ID2
Field Name Bits Type Reset Value Description
REVISION 7:4 ro 0x0 Revision
JEDEC 3 ro 0x1 JEDEC used
JEP106 2:0 ro 0x4 JEP106 Identity [6:4]
Name FTMPERIPHID3
Relative Address 0x00000FEC
Absolute Address 0xF880BFEC
Width 8 bits
Access Type ro
Reset Value 0x00000000
Description Peripheral ID3
Field Name Bits Type Reset Value Description
RevAnd 7:4 ro 0x0 RevAnd
CustMod 3:0 ro 0x0 Customer Modified
