Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1056
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (ftm) FTMCOMPONID0
Register FTMCOMPONID0 Details
Register (ftm) FTMCOMPONID1
Register FTMCOMPONID1 Details
Register (ftm) FTMCOMPONID2
Name FTMCOMPONID0
Relative Address 0x00000FF0
Absolute Address 0xF880BFF0
Width 8 bits
Access Type ro
Reset Value 0x0000000D
Description Component ID0
Field Name Bits Type Reset Value Description
Preamble 7:0 ro 0xD Preamble
Name FTMCOMPONID1
Relative Address 0x00000FF4
Absolute Address 0xF880BFF4
Width 8 bits
Access Type ro
Reset Value 0x00000090
Description Component ID1
Field Name Bits Type Reset Value Description
CompClass 7:4 ro 0x9 Component Class :CoreSight Component
Preamble 3:0 ro 0x0 Preamble
Name FTMCOMPONID2
Relative Address 0x00000FF8
Absolute Address 0xF880BFF8
Width 8 bits
Access Type ro
Reset Value 0x00000005
