Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1059
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (funnel) Control
Register Control Details
PERIPHID3 0x00000FEC 8 ro 0x00000000 Peripheral ID3
COMPID0
0x00000FF0 8 ro 0x0000000D Component ID0
COMPID1
0x00000FF4 8 ro 0x00000090 Component ID1
COMPID2
0x00000FF8 8 ro 0x00000005 Component ID2
COMPID3
0x00000FFC 8 ro 0x000000B1 Component ID3
Name Control
Relative Address 0x00000000
Absolute Address 0xF8804000
Width 12 bits
Access Type rw
Reset Value 0x00000300
Description CSTF Control Register
Register Name Address Width Type Reset Value Description
Field Name Bits Type Reset Value Description
MinHoldTime 11:8 rw 0x3 The formatting scheme can easily become
inefficient if fast switching occurs, so, where
possible, this must be minimized. If a source has
nothing to transmit, then
another source is selected irrespective of the
minimum number of cycles. Reset is 0x3. The
CSTF holds for the minimum hold time and one
additional cycle.
The mFunnelum value that can be entered is 0xE
and this equates to 15 cycles.
0xF is reserved.
EnableSlave7 7 rw 0x0 Setting this bit enables this slave port. If the bit is
not set then this has the effect of excluding the
port from the priority selection scheme.
EnableSlave6 6 rw 0x0 Setting this bit enables this slave port. If the bit is
not set then this has the effect of excluding the
port from the priority selection scheme.
EnableSlave5 5 rw 0x0 Setting this bit enables this slave port. If the bit is
not set then this has the effect of excluding the
port from the priority selection scheme.
EnableSlave4 4 rw 0x0 Setting this bit enables this slave port. If the bit is
not set then this has the effect of excluding the
port from the priority selection scheme.
