Appendix B: Register Details
Register IMCR Details
Register (funnel) CTSR
Register CTSR Details
Register (funnel) CTCR
Absolute Address 0xF8804F00
Width 1 bits
Access Type rw
Reset Value 0x00000000
Description Integration Mode Control Register
Field Name Bits Type Reset Value Description
0 rw 0x0 Enable Integration Test registers.
Name CTSR
Relative Address 0x00000FA0
Absolute Address 0xF8804FA0
Width 4 bits
Access Type rw
Reset Value 0x0000000F
Description Claim Tag Set Register
Field Name Bits Type Reset Value Description
3:0 rw 0xF The claim tag register is used for any
interrogating tools to determine if the device is
being programmed or has been programmed.
Read:
1= Claim tag is implemented, 0 = Claim tag is not
implemented
Write:
1= Set claim tag bit, 0= No effect
Name CTCR
Relative Address 0x00000FA4
Absolute Address 0xF8804FA4
Width 4 bits
Access Type rw
