Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 107
UG585 (v1.11) September 27, 2016
Chapter 3: Application Processing Unit
3.6 Support for TrustZone
TrustZone is hardware that is built into all Zynq-7000 AP SoC devices. For more information, see
Programming ARM TrustZone Architecture on the Xilinx Zynq-7000 All Programmable SoC (UG1019).
3.7 Application Processing Unit (APU) Reset
3.7.1 Reset Functionality
The APU supports several reset modes that enable you to reset different parts of the block
independently. Applicable resets and their functions are as follows:
The APU supports different reset modes that enable the user to reset different parts of the block
independently. Applicable resets and their functions are as follows:
Note: The APU in Zynq-7000 AP SoC devices does not support an independent reset for the NEON
coprocessors.
37 Performance monitor unit (PMU) of CPU0
38 Performance monitor unit (PMU) of CPU1
Table 3-8: APU Interrupts
Interrupt Description
Power-on Reset The power-on reset or cold reset is applied when the power is first
applied to the system or through the PS_POR_B device pin. In this
reset mode, both CPUs, the NEON coprocessors, and the debug logic
is reset.
System Reset A system reset initializes the Cortex-A9 processor and the NEON
coprocessors, apart from the debug logic. Break points and watch
points are retained during this reset. This reset is applied through the
PS_SRST_B device pin.
Software Reset A software or warm reset initializes the Cortex-A9 processor and the
NEON coprocessors, apart from the debug logic. Break points and
watch points are retained during this reset. Processor reset is
typically used for resetting a system that has been operating for
some time. This reset is applied through the
A9_CPU_RST_CTRL.A9_RSTx register.
System Debug Reset This reset is similar to the software reset; however, it is triggered
through the JTAG interface.
Debug Reset This reset initializes the debug logic in a Cortex-A9 processor,
including break point and watch point values. It is triggered through
the JTAG interface.
