Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1109
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register ITTRIGOUT Details
Register (itm) ITATBDATA0
Register ITATBDATA0 Details
Register (itm) ITATBCTR2
Register ITATBCTR2 Details
Description Integration Test Trigger Out Register
Field Name Bits Type Reset Value Description
ITTRIGOUT 0 wo 0x0 Set the value of TRIGOUT
Name ITATBDATA0
Relative Address 0x00000EEC
Absolute Address 0xF8805EEC
Width 2 bits
Access Type wo
Reset Value 0x00000000
Description Integration Test ATB Data Register 0
Field Name Bits Type Reset Value Description
ITATDATAM7 1 wo 0x0 Set the value of ATDATAM[7]
ITATDATAM0 0 wo 0x0 Set the value of ATDATAM[0]
Name ITATBCTR2
Relative Address 0x00000EF0
Absolute Address 0xF8805EF0
Width 1 bits
Access Type ro
Reset Value 0x00000001
Description Integration Test ATB Control Register 2
Field Name Bits Type Reset Value Description
ITATREADYM 0 ro 0x1 Read the value of ATREADYM
