Appendix B: Register Details
Register (itm) ITATABCTR1
Register ITATABCTR1 Details
Register (itm) ITATBCTR0
Register ITATBCTR0 Details
Register (itm) IMCR
Name ITATABCTR1
Relative Address 0x00000EF4
Absolute Address 0xF8805EF4
Width 7 bits
Access Type wo
Reset Value 0x00000000
Description Integration Test ATB Control Register 1
Field Name Bits Type Reset Value Description
ITATIDM 6:0 wo 0x0 Set the value of ATIDM[6:0]
Name ITATBCTR0
Relative Address 0x00000EF8
Absolute Address 0xF8805EF8
Width 2 bits
Access Type wo
Reset Value 0x00000000
Description Integration Test ATB Control Register 0
Field Name Bits Type Reset Value Description
ITAFREADYM 1 wo 0x0 Set the value of AFREADYM
ITATVALIDM 0 wo 0x0 Set the value of ATVALIDM
Name IMCR
Relative Address 0x00000F00
Absolute Address 0xF8805F00
Width 1 bits
Access Type rw
Reset Value 0x00000000
